bizhub C301i MFP, Laser, Color - Configurations: 17
• Copy • Network Print • Network Scan • Fax (optional)
The price is valid for the standard configuration
VI-508 Video Interface Card for IC-416 Fiery Image Controller
1.208
Lei
Konica Minolta bizhub C301i - SRA3 Color Laser MFP;
Key Features
• 30/15 ppm in colour and black & white.
• Paper formats: A6-SRA3, custom formats and banner format up to 1.2 metres lengt.
• 9-inch colour touch panel with multi-touch support and dedicated mobile touch area for more convenience and flexibility in today's working style.
• Reduced environmental impact thanks to state-of-the-art technology ensuring competitively low energy consumption – which saves both energy and money.
• Highest data security thanks to various security functionalities to reduce the risk of data loss and keep confidential data safe.
Print from anywhere, anytime...
“When you’re on the same Wi-Fi network, you’re able to print just about anything your device can display”
- You can automatically search for and print to bizhub devices on the same network as your iPhone or other device.
- Data can be sent via a wireless LAN to AirPrint-compatible bizhub devices for printing of files such as e-mails, photos and web pages.
- You can set the number of copies to be printed and single- or double-sided printing.
Mopria Print Service
The Mopria Print Service is an application which lets you print directly from devices running Android 4.4 (KitKat) or later.
- Documents such as photographs, web pages and PFD files can be printed easily via a wireless LAN to Mopria-certified output devices.
- You can search automatically for different MFPs on the same network.
- You can print documents such as e-mails, photos and web pages from MFPs which are compatible with the Mopria Print Service via a wireless LAN.
- You can set the number of prints and also change colour and b/w settings.
Wireless LAN Access Point Mode
- For environments without Wireless Network, compatible Konica Minolta MFPs now have the capability to deliver their own Wireless LAN, thanks to the Wireless LAN Access Point Mode, without the need for a third party access point (router).
- To be an interface user look for a WiFi network and select the bizhub network. Once connected, you are ready to print to this bizhub system.
- It may be necessary to update the device firmware.
- Up to five units can be connected at one time.
Google Cloud Print
- Google Cloud Print is a printing service provided by Google which connects your Konica Minolta printer or MFP to the web via smartphones, tablets, Chromebook, PC or any other web-connected device in use for your application.
- Print from a wide range of devices, such as smartphones and tablet devices with iOS or Android.
- OS, and also Windows and Mac PCs; no extra printer drivers needed.
- Send print jobs to your office printer via the Cloud even while you're out of the office.
Basic functionalities
Print
- Emperon™ print controller - Konica Minolta's high-performance controller with support of PostScript3, PCL6, PCL 5e/c and XPS.
- Direct print - driverless printing of PDF, XPS, DOCx, XLSx, PPTx, JPEG, TIFF, PS and PCL.
- Carbon copy print - single page printing from multiple trays with different design.
- Banner printing - Print of 1.2 m long banners.
- Mobile Printing - Possibility to directly print documents from a mobile device.
Copy
- Job preview - illustrates selected copy functions on screen.
- Custom function bar - up to 2 x 7 copy functions can be freely selected for the main copy screen.
- Blank page removal - automatic deletion of blank pages e.g. when copying mixed simplex and duplex documents.
- High-performance document feeder - fast scanning of originals with duplex document feeder.
- Mixed original scanning - automatic scanning of originals with different formats.
Scan
- Scan to Me/Home - direct scan to own email address (Me) or SMB folder (Home) based on Active Directory information.
- Scan preview - provides a realtime preview of scanned originals for checking before sending.
- Scan annotation - stamping of e.g. date/time, filing number or custom text on scans for archiving purposes.
- Scan programs - presetting of original, scan file and destination for regular scan jobs.
- Blank page removal - automatic deletion of blank pages e.g. when scanning mixed simplex and duplex documents.
- Addressbook - MFP and network based address books can be used and searched.
Fax
- IP Fax - sending of fax messages via network between Konica Minolta MFPs; supports colour and b/w.
- PC Fax - direct fax transmission from the PC.
- Fax forward - forwarding of incoming fax documents by email or to SMB folder instead of printing.
- Shared address book - the MFP internal address book can be shared to the PC fax client.
- Convenient fax distribution - Fax destinations can be preconfigured in an adressbook.
Box Unit
- Box function - Storing of print, copy, scan and fax jobs for recall to send and print
- Personal, Group and Public User - access definition for different boxes
- Sharing - copying of documents from user box to user box
- Online access userbox - file access via web browser or box operator utility
- Auto deletion - automatic deletion of user box stored files after a definable period
Security
- Authentication - user access by password, username + password or fingervein scanner
- Access rights function - access rights can be granted on user level (up to 1000 accounts on MFP)
- Data encryption - encryption of data stored on hard disc and password protection for hard disc access
- Network security - copy, print, scan and fax job data are automatically deleted after job completion
- Network security - Support for SSL/TLS, HTTPS, 802.1x and IPsec.
Green
- Dynamic eco Timer - automatic analysis of working hours and adjustment of sleep mode timing
- ECO scan - scanning of documents without warm-up of the print engine
- ECO print - touchscreen panel does not light up for printing out of sleep mode
- Weekly timer - sleep mode timer setting on day and date basis
- ECO meter - counter for eco related items e.g. power consumption.
Control Panel
Optional accessories
• Original Cover OC-511 - used in the absence of an automatic document feeder;
• Document feeder DF-632 - Reversible automatic document feeder. Capacity max. 100 originals;
• • Document feeder DF-714 - Dual scan document feeder. Capacity max. 100 originals;
• Paper Feed Cabinet PC-116 - Allows you to load up to 500 sheets in the top tray and use the bottom tray as a storage box.
• Paper Feed Cabinet PC-216 - Allows you to load up to 1000 sheets respectively in the top and bottom trays.
• Paper Feed Cabinet PC-416 - Allows you to load up to 2,500 sheets A4 size.
• Large Capacity Unit LU-302 - housing A4 format (3,000) sheets, brings maximum paper supply to 6,650 sheets.
• Banner Tray BT-C1e - Used to print data on banner paper (max. 297 x 1200 mm).
• Desk DK-516x - Used to install this machine on the floor and storing consumables and paper.
• Finisher FS-533 - Install this unit onto the output tray of this machine. Sorts, groups and staples printed paper before outputting it.
• Punch Kit PK-519 - Install this unit onto Finisher FS-533. This unit supports the punching function.
• Finisher FS-536 - Sorts, groups and staples printed paper before outputting it. To install Finisher FS-536, Desk DK-516x, Paper Feed Cabinet PC-416, Paper Feed Cabinet PC-116, or Paper Feed Cabinet PC-216 must be installed onto this machine.
• Finisher FS-536SD - Sorts, groups, staples and fold/bind function. To install Finisher FS-536SD, Desk DK-516x, Paper Feed Cabinet PC-416, Paper Feed Cabinet PC-116, or Paper Feed Cabinet PC-216 must be installed onto this machine.
• Punch Kit PK-520 - Install this unit onto Finisher FS-534. This unit supports the punching function.
• Job Separator JS-506 - Install this unit onto the output tray of this machine. This unit sorts printed sheets.
• Working Table WT-506 - Provides an area to temporarily place an original or other materials. This is also used when the Authentication Unit is installed.
• Authentication Unit AU-102 - Performs user authentication by scanning vein patterns in the finger. The Working Table WT-506 is required to install Authentication Unit AU-102.
• Keyboard Holder KH-102 - Install this holder to use a external keyboard. For details on external keyboards, contact your service representative.
• Fax Kit FK-514 - Used to operate this machine as a fax machine. Alternatively, this kit allows more telephone lines to be connected.
• Stamp Unit SP-501 - Stamps a scanned original when sending a fax. This unit allows you to check that the original has been scanned.
• Spare TX Marker Stamp 2 - A replacement stamp for the Stamp Unit SP-501.
• Image Controller IC-420 - Installing this unit will provide higher quality printing result. Video Interface Kit VI-516 is required to install Image Controller IC-420. Also, Desk DK-516x, Paper Feed Cabinet PC-416, Paper Feed Cabinet PC-116, or Paper Feed Cabinet PC-216 must be installed onto this machine.
• Video Interface Kit VI-516 - This unit is required to install Image Controller IC-420.
• Interface UK-115 - for image controller Fiery IC-420
• Local Interface Kit EK-608 - Install this unit when using the external keyboard or voice guidance. This unit is equipped with a speaker.
• Local Interface Kit EK-609 - Install this unit when connecting to the external keyboard or Bluetooth-enabled device. This unit is equipped with a speaker, voice guidance and a receiving device for Bluetooth communication.
• Security Kit SC-509 - Supports the copy guard and password copy functions to prevent unauthorized copying (2 licenses SC-509 required).
• UK-221 Wireless LAN - Wifi model for both bizhub Remote Access and normal Wi-fi connection. Required for bizhub Remote Access on Android and iOS and for wireless LAN Access Point Mode. (for UK-221 to be installed, EK608 or EK-609 is required);
• i-Option License LK-102v3 - Supports the PDF processing function that is one of the advanced functions.
• i-Option License LK-105v4 - Supports the searchable PDF function that is one of the advanced functions.
• i-Option License LK-106 - Used to add a bar code font that is one of special fonts.
• i-Option License LK-107 - Used to add a unicode font that is one of special fonts.
• i-Option License LK-108 - Used to add an OCR font that is one of special fonts.
• i-Option License LK-110v2 - Generation of file formats: DOCX, XLSX & PDF/A.
• i-Option License LK-111 - ThinPrint Client Function. Print data compression for reduced network impact.
• i-Option LicenseLK-114 - Secure and Follow Me printing solution requiring no server application
• i-Option License Kit LK-115v2 - Trusted Platform Module (TMP) for protection of data encryption and decryption.
• i-Option License Kit LK-116 - BitDefender antivirus software
Standard
Unitate automată față-verso
◦ Tip: fără stocare;
◦ Formate acceptate: A6*, A5, B6*, A4, SRA4, B4, A3, A3 Wide, SRA3;
◦ Greutatea hârtiei: 52 - 256 g/m²;
Notă: pentru copiere automată față-verso, se instalează RADF DF-632 sau DSDF DF-714.
* A6 și B6 - numai pe lungime (peisaj)
Finishing
Opționale disponibile:
◦ JS-506 Separator de lucrări: separă faxurile de imprimate și stochează maxim 250 de file:
◦ FS-533 Finisor Intern tip : sortează/grupează prin deplasare, capsează maxim 50 file și stochează maxim 500 file;
◦ FS-536 Finisor capsator: sortează, grupează, sortează/grupează prin deplasare, capsează 50 file și stochează 3.300 file;
◦ FS-536SD Finisor de broșurare: sortează, grupează, sortează/grupează prin deplasare, capsează 50 file, pliază, broșurează 20 de file și stochează 2.300 file.
◦ PK-519 Perforator: 2 sau 4 găuri în linie (deservește FS-533);
◦ PK-520 perforator: 2 sau 4 găuri în linie, (derservește FS-536 și 536SD);
Standard interface
◦ 10-Base-T/100-Base-T/1000-Base-T Ethernet;
◦ USB 2.0 interfață locală;
◦ USB host (direct print).
Interface (optional)
◦ SX-BR-4600 interfață locală Wireless Bridge;
◦ EK-608 USB host pentru tastatură externă, activează îndrumarea vocală, include difuzor;
◦ EK-609 Bluetooth LE, USB host pentru tastatură externă, activează îndrumarea vocală, include difuzor;
◦ UK-221 Wireless LAN / Punct de Acces (solicită EK-608 sau EK-609).
Accounting
◦ Până la 1.000 conturi utilizatori, suport Active Directory (nume utilizator + parola + email + folder SMB);
◦ Definire acces utilizatori;
◦ Autentificare biometrică (scanarea dispunerii venelor în deget) opţional;
◦ Autentificare prin card IC-Card (cititor IC-Card ) opţional;
PROCESSOR & MEMORY
Processor
CPU Cortex A72 CPU Quad Core 1.8GHz
Standard memory
8 GB RAM
Hard disk
SSD 256 GB
Box unit
• Memorie instalată: SSD 256 GB
• Memorie de documente:
◦ 3.000 documente sau
◦ 10.000 pagini
• Utilizator BOX
◦ Public
◦ Personal (acces cu parolă sau autentificare)
◦ Grup (cu autentificare)
• Sistem BOX
◦ Imprimare Securizată
◦ Imprimare PDF criptat
◦ Recepție Fax
◦ Fax polling
• Funcții BOX
◦ Reimprimare
◦ Combinare
◦ Download
◦ Transmisie (e-mail/FTP/SMB și Fax)
◦ Copiere BOX-to-BOX
COPIER
Resolution max.
600 x 600 dpi
Gray scale
256
Zoom (min.-max.)
25 - 400% în trepte de 1%
+ Autozooming
Copy select
1 - 9999
Density adjustment
Automat / Manual (9 trepte)
Image loss
sus: 4,2 mm; jos/dreapta/stânga: 3 mm
Special function
◙ 2in1/4in1/8in1, ◙ AMS/APS, ◙ Book copy, ◙ Booklet creation, ◙ Chapter insertion, ◙ Continuous number stamping, ◙ Cover mode, ◙ X/Y independent zoom, ◙ Distribution numbering, ◙ Edge / Frame / Fold line erase, ◙ Image insertion, ◙ Image repeat, ◙ Image shift, ◙ Image rotation, ◙ Program job, ◙ Non-image area erase, ◙ OHP interleaving, ◙ Overlay, ◙ Page insertion, ◙ Positive-negative-mode, ◙ Date stamp / Page stamp, ◙ Electronic print / Rotation print out / Criss-cross sorting, ◙ Program memory (30), ◙ Proof copy, ◙ Separate scanning, ◙ Stamp, ◙ Watermark, ◙ Gloss copy, ◙ Enlarge display, ◙ Account track / Department control (1000), ◙ User authentication, ◙ Copy protection.
PRINTER
Resolution max.
◦ 1.800 (echivalent) x 600 dpi;
◦ 1.200 x 1.200 dpi.
◦ Citrix;
◦ Linux;
◦ Macintosh OS X 10.10;
◦ SAP;
◦ Windows 7 (32/64);
◦ Windows 8/8.1 (32/64);
◦ Windows 10 (32/64);
◦ Windows Server 2008 (32/64);
◦ Windows Server 2008 R2;
◦ Windows Server 2012/R2;
◦ Windows Server 2016;
◦ Windows Server 2019;
Network protocols supported
Supported protocols:
TCP/IP (IPv4/IPv6), BOOTP, ARP, ICMP, DHCP, DHCPv6, AutoIP, SLP, SNMP, FTP, LPR/LPD, RAW Socket, SMB over TCP/IP, IPP, HTTP, POP, SMTP, LDAP, NTP, SSL, IPX, AppleTalk, Bonjour, NetBEUI, WebDAV, DPWS, S/MIME, IPsec, DNS, Dynamic DNS, LLMNR, LLTD, SSDP, SOAP. Supported LDAP Servers:
Open LDAP 2.1x, Active Directory, Exchange 5.5/2000/2003, Sun Java Directory Server (Netscape / iPlanet Directory Server), Novell NetWare 5.x/6.x NDS, Novell eDirectory 8.6/8.7, Lotus Domino Server (5.x/6.x)*
*When using the Lotus Domino Server, and setting the search condition to OR, the function will not work correctly.
Security
◦ ISO 15408/IEEE 2600.1 (in evaluation);
◦ Filtrare IP şi blocare porturi / IP filtering and port blocking;
◦ Criptare comunicare în reţea SSL2, SSL3 si TSL1.0 / SSL2; SSL3 and TSL1.0 network communication;
◦ IPsec support;
◦ IEEE 802.1x support;
◦ Autentificare utilizatori / User authentication;
◦ Raport autentificare / Authentication log;
◦ Imprimare securizată / Secure Print;
◦ Suprascriere hard disk (8 tipuri standard) / Hard disc overwrite (8 standard types);
◦ Criptare date pe hard disc / Hard disc data encryption AES 256;
◦ Ștergere automată a datelor din memorie / Memory data auto deletion;
◦ Mirroring HDD (opțional);
◦ Recepţie confidenţială a faxurilor / Confidential fax receiving;
◦ Criptare documente utilizator / Print user data encryption;
◦ Protecţie la copiere (copy guard, parola) / Copy Protection (copy guard, password)
◦ Autentificare biometrica (scanarea dispunerii venelor în deget) / Biometric Login.
Konica Minolta applications
◦ Download Center Application;
◦ Download Manager for Windows;
◦ Download Manager for Macintosh;
◦ Driver Packaging Utility;
◦ Font Management Utility;
◦ HDD Backup Utility;
◦ Log Management Utility;
◦ PageScope Box Operator;
◦ PageScope Data Administrator;
◦ PageScope Direct Print;
◦ PageScope Net Care Device Manager;
◦ PageScope Net Care Device Manager Plug-In;
◦ Print Status Notifier.
POWER SUPPLY, ENVIRONMENT & DIMENSIONS
Power supply
220/240 Va.c. ± 10%;
50 Hz ± 6%;
Power consumption
< 1580 W
Operating temperature
10 ~ 30°C (max. ±10°C)
Operating humidity
15 ~ 85% RH (max. ±10%/h)
Dimensions (w x d x h)
615 x 688 x 779 mm
Weight
84 kg (fără ADF, Cabinet si Capac OC-511)
Warranty
12 luni (sau maxim 300.000 de imprimate A4)
DELIVERED PRODUCT INCLUDES:
Configurația standard
Konica Minolta bizhub C301i:
- Memorie RAM 8GB;
- Unitate BOX (SSD 256GB);
- Unitate Duplex pentru imprimare față-verso;
- Multibypass lateral: 150 file, hârtie, carton, plicuri, etc.;
- Caseta 1: 500 file A5, A4 sau A3;
- Caseta 2: 500 file A5, A4, A3 sau SRA3;
- CD-ROM cu manuale de utilizare, programe driver și utilitare PageScope.
Rezervă totală de hârtie: 1.150 file.
Materiale consumabile incluse:
- 1 Cilindru K (negru) pentru 225.000 pagini (format A4, 5%);
- 3 Cilindri C (cyan), M (magenta), Y (galben), pentru 90.000 pagini;
- 4 Unități de developare C, M, Y, K, pentru 1.000.000 pagini.
Notă:
Tonerele C, M, Y, K, conform uzanțelor NU sunt incluse în preț.
TERMS OF DELIVERY
◦ ATEC Global Systems livreaza gratuit echipamente Konica Minolta la sediul cumparatorului, numai pe raza Municipiului Bucuresti.
◦ În restul teritoriului livrările se fac prin intermediul unei firme de curierat acreditată oficial și preferată de către destinatar.
Detalii prin telefon la: 021.231.1177, 021.231.1176, 021.230.0147 sau prin posta electronica la: office@atec.ro , sales@atec.ro.
